AutoFocus II Trace Probe V2
AutoFocus II Trace Probe V2
Preprocessor for recording parallel off-chip trace
for with up to 36 signals from one or two Mictor38 connectors,
suitable for ETM, PFT, Trax, RTT, Nexus, MIPI and more.
Requires PowerTrace II / III, PowerTrace PX
or PowerTrace Ethernet Version 6 or higher.
Variable threshold level and termination voltage.
AUTOFOCUS self calibration technology.
Voltage: 1.2 to 3.3V.
Traceport: 1 - 36 bit.
Bandwidth: Up to 600+ Mbit/s per pin.
Connector: 2x38 pin Mictor connector.
This product can only be ordered as part of a package, not separately.
This TRACE32 Product is a license carrier. It requires a
suitable, programmed TRACE32 A-license.
Technical Information
Technical Data
INCLUDED PRODUCTS:
Included in the Following Products
Available in
This product is part of the following product bundles.
- LA-3300 AutoFocus II Trace Probe for RISC-V
- LA-3308 AutoFocus II Trace Probe for Arm ETM
- LA-3312 AutoFocus II Trace Probe for Xtensa®
- LA-3316 AutoFocus II Trace Probe for ARC® RTT
- LA-3330 AutoFocus II Trace Probe for C6000
- LA-3335 AutoFocus II Trace Probe for CEVA-X
- LA-3339 AutoFocus II Trace Probe for RH850
- LA-3341 AutoFocus II Trace Probe for VSPA
- LA-3346 AutoFocus II Trace Probe for C7000
- LA-3351 AutoFocus II Trace Probe for PPC4xx
- LA-3355 AutoFocus II Trace Probe for RAM Trace Port
- LA-3356 AutoFocus II Trace Probe for SuperH (SH) AUD
- LA-3357 AutoFocus II Trace Probe for Nios® II
- LA-3358 AutoFocus II Trace Probe for STRED
- LA-3359 AutoFocus II Trace Probe for Beyond
- LA-3360 AutoFocus II Trace Probe for TeakLite III
- LA-3361 AutoFocus II Trace Probe for MicroBlaze™
Extend the AutoFocus II Trace Probe V2
Allowed Licenses
The following licenses can be added to the product to support debug and/or tracing of other core architectures.
- LA-2752A STRED Trace License (trace tool)
- LA-2754A Xtensa® Trace License (trace tool)
- LA-2761A C7000 Trace License (trace tool)
- LA-2767A RISC-V Trace License (trace tool)
- LA-2901A VSPA Trace License (trace tool)
- LA-3734A RH850 Trace License (trace tool)
- LA-3900A PPC4xx Trace License (trace tool)
- LA-3901A MicroBlaze™ Trace License (trace tool)
- LA-3904A TeakLite Trace License (trace tool)
- LA-3908A Beyond Trace License (trace tool)
- LA-3914A ARC® Trace License (trace tool)
- LA-3917A Nios® II Trace License (trace tool)
- LA-7970A Arm® Trace License (trace tool)
- LA-7973A SuperH (SH) Trace License (trace tool)
- LA-7977A Ceva®-X™ Trace License (trace tool)
- LA-7979A C6000 Trace License (trace tool)
- LA-7999A StarCore Trace License (trace tool)
Available Converters
- LA-1371 Mictor Flex Extension Long
- LA-2735 Conv. AF2+Debug to RH850 Mictor Pinout
- LA-2785 Conv. Samtec40 HSSTP and 2xMictor38 to FMC
- LA-3727 Converter Mictor38/IDC20A to 60 Pin CTOOLS
- LA-3768 ETMv1 Conv. Mictor-38, 2x MIPI-34 to MIPI-60
- LA-3769 Conv. Mictor-38, 2x MIPI-34 to MIPI-60
- LA-3804 Converter Mictor 38 to XILINX XGI
- LA-3805 Converter Mictor 38 to S3EStarter/MicroBlaze
- LA-3806 Converter Mictor 38 to S3ADSPStarter/MicroBla
- LA-3808 Conv. L8540 2xMic38/2xMIPI34/IDC20A to MIPI60
- LA-3809 Converter Mictor-38/IDC20A to MIPI-20T
- LA-3812 Conv. OMAP4 2xMic38/IDC20A/MIPI34 to MIPI60
- LA-3814 ETMv3 Conv. Mictor-38/MIPI-34 to MIPI-60
- LA-3816 Converter 2x Mictor-38 to MIPI-60
- LA-3818 Converter 2xMictor38/IDC20A to MIPI-60
- LA-3820 Converter Mictor38 to Hirose36 for SHx
- LA-3835 Conv. Mictor38/ETM+IDC20A to Mictor-38/RTP
- LA-3842 Converter Mictor-38/IDC20A to MIPI-34
- LA-3884 Converter Mictor38 to PolarFire® SoC Kits
- LA-3897 Conv. Mic38 to SABRE-AI Board
- LA-7646 Converter Mictor38 to 2.54 mm flying leads
- LA-7649 Converter Mictor38 to 2.54 mm Connector
- LA-7858 Converter from 2 Mictor to AMP MODU SYSTEM50
- LA-7901 EJTAG MIPS32 Converter Mictor38 to Samtec24
- LA-7903 EJTAG MIPS32 Converter Mictor38 to Samtec52
- LA-7908 EJTAG MIPS32 Converter Mictor38 to Samtec52
- LA-7909 Converter Mictor38 to Samtec40 for PP-MIPS
- LA-7920 Converter Vertical to Horizontal for MICTOR
- LA-7922 Levelshifter for trace probes at 5V targets
- LA-7983 Conv. 38 Pin Mictor to 20 for Preproc. PPC4xx
- LA-7986 Converter PPC4xx-16 and Mictor38 to Mictor38
