ARM9 Debug License Ext. (tool locked)
ARM9 Debug License Ext. (tool locked)
License for debugging of ARM9 cores based on the ARMv4T or
ARMv5TE architecture applicable to an existing IDC20A Debug Probe.
with an existing Arm debug license and a valid warranty contract.
(This is NOT for Armv9 based Cortex-A cores.)
Includes license for multicore debugging.
Includes TRACE32 software for Windows, Linux and macOS
on DVD or via download.
Requires a Debug Probe (cable) and PowerDebug base module.
If you are adding this license to an existing
Debug Probe (Debug Cable or CombiProbe),
add its serial number to your quotation request.
HS-Code / Tariff-Code: 85234910
Technical Information
Programmable To:
The License can be added to one of the following products.
- LA-3249 IDC20A Debug Probe with ARM10 License
- LA-3250 IDC20A Debug Probe with ARM7 License
- LA-3252 IDC20A Debug Probe with ARM11 License
- LA-3253 IDC20A Debug Probe with Armv7-A/R License
- LA-3254 IDC20A Debug Probe with Cortex-M License
- LA-3255 IDC20A Debug Probe with Armv8/v9-A/R License
- LA-3258 IDC20A Debug Probe with JANUS License
- LA-7746 JTAG Debugger for Arm7 20 Pin Connector (ICD)
- LA-7762A XScale Debug License (tool locked)
- LA-7765 JTAG Debugger for Arm11 (ICD)
Extend the ARM9 Debug License Ext. (tool locked)
Allowed Licenses
The following licenses can be added to the product to support debug and/or tracing of other core architectures.
