PowerTrace Serial

OVERVIEW

Rocket Fast Tracing

State-of-the-art trace module that covers all high-speed serial trace ports from low lane count, low bit rate up to the highest lane count and fastest bit rate available in the embedded market. All chips with serial trace port supported. Not only supporting the Aurora/HSSTP protocol, but also excellent support for tracing over PCIe.

BENEFITS

Lorem Ipsum dolor sit amet

Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum.

Widest support of SoCs

PowerTrace Serial does not only support serial trace for ARM CoreSight or Infineons AGBT, but also for many other CPU architectures - as long as your SoC has serial trace interface. Lauterbach is working closely with chip manufacturers to make sure that the SoC of your next project is already fully supported at the time it hits your desk.

Off-chip tracing without trace port

Stream trace data to PCIe ports you have already designed and placed. If you can´t afford the physical space on your target for a dedicated trace port, but your SoC already supports PCIe, PowerTrace Serial will act as a PCIe endpoint for trace data. Save the money for additional high-speed transceivers.

Converters are available for PCIe and mini PCIe, including slot-card adapters, to connect Power-Trace Serial to your board.

Perfect choice for high-speed SoCs

Capture the program flow, task switches, data of several cores and other system sources at once in far more details compared to other tools. With the fast bit rate of up to 100 GBit/s and large data buffers, PowerTrace Serial allows you to explore the operation of your device from the top-level module interactions to the timing of individual instructions.

The super pursuit mode for Aurora

Out of the box PowerTrace Serial supports up to 12.5 Gbit/s per lane. When you need more, simply add the Aurora 2 Preprocessor to the Power Trace Serial to record lanes with up to 22.5 Gbit/s per lane. Thanks to the modular design, even higher bit rates are going to be supported in the near future.

Future Proof Design

Update your debug solution as you update your design. With Lauterbach’s modular design, you use the same debug solution across multiple target architectures with minimal changes.

TECHNICAL DATA

Technical Data for PowerTrace Serial

VARIANTS

Lorem Ipsum dolor sit amet

TARGET CONNECTION

Lorem Ipsum dolor sit amet

TYPICAL CONFIGURATIONS

Configuration Examples for PowerTrace Serial


ARM HSSTP Trace

Description:

Products shown:

  • LA-3505 PowerDebug PRO
  • LA-3255 Debug Cable for Cortex-A/R (Armv8 and Armv9)
  • LA-3310 Trace for Arm-ETM via PT-Serial 4GB
  • LA-3521 Accessories for PTSerial for ARM-ETM 1-6 Lanes

HSSTP Ultra-speed

Description:

Products shown:

  • LA-3505 PowerDebug PRO
  • LA-3255 Debug Cable for Cortex-A/R (Armv8 and Armv9)
  • LA-3310 Trace for Arm-ETM via PT-Serial 4GB
  • LA-3945 Preprocessor Aurora 2 for PowerTrace Serial

Tricore AGBT

Description:

Products shown:

  • LA-3505 PowerDebug PRO
  • LA-3203 Debug Cable for TriCore AUTO26
  • LA-3306 Trace for TriCore via PTS 4GB

PowerPC QorIQ via PCIe

Description:

Products shown:

  • LA-3505 PowerDebug PRO
  • LA-3794 DebugCable for QorIQ PowerPC 64-Bit
  • LA-3570 PowerTrace Serial 4 GigaByte QorIQ PowerPC
  • LA-3550X License for PCI Express
  • LA-3572 Accessories for PTSerial PCIe x4 Slot-Card

EXTENSIONS

Lorem Ipsum dolor sit amet

Preprocessor Aurora

Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet. Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.
