Supports C7000. Only suitable for debug cables newer than 08/2008 Please add the base serial number of your existing debug cable to your order.

supports dsPIC33C (0.9 V - 5.5 V) Debugging of dual-core dsPIC requires LA-2762 Package for CombiProbe 2 dsPIC Dual Core includes software for Windows, Linux and macOS requires PowerDebug Interface USB 2.0/USB 3.0, PowerDebug Ethernet, PowerDebug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50 AUTO26 debug cable

supports dsPIC33C Debugging of dual-core dsPIC requires LA-2762 Package for CombiProbe 2 dsPIC Dual Core Adaptation to MICROCHIP-8 requires LA-2773 Conv. AUTO26 to MICROCHIP-8 LA-1949 Automotive HALF-SIZE-CABLE 26-26 only suitable for debug cables newer than 07/2018 please add the serial number of the existing debug cable to your order includes software for Windows, Linux and macOS

Enables trace decoding for C7000 . Please add the base serial number of your existing debug cable to your order.

Two whisker cables to support dual core debugging 26-pin Automotive Connector requires the following A-license: LA-2760A (Debugger for PIC Additional) LA-7960X (License for Multicore Debugging ) requires Power Debug Interface USB 3.0, Power Debug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50 voltage range 1.8 to 5.0

Converter from IDC20A to 12 pin PMOD connectors with the JTAG pinout from SiFive. The adapter exists in two variants: with male and female PMOD connector. This adapter has the male PMOD connector. PMOD is an open standard defined by Digilent for peripherals used with FPGAs or microcontrollers. The PMOD pinout of this adapter does ONLY work with targets that use the pinout that was defined by SiFive. So it is not a general/official RISC-V pinout. In case of FPGA boards, the pinout may depend on the used FPGA image.

Trace license to support trace decoding for RISC-V, applicable to AutoFocus II or a PowerTrace Serial. Tested for SiFive Nexus IP. Tested for Trace Encoder IP from Tessent Embedded Analytics (former UltraSoC) . Other IP on request If the license is applied to an AutoFocus II preprocessor, the preprocessor must have a base serial number of C1210xxxxxxx or higher. Please add the base serial number of your existing AutoFocus II preprocessor or PowerTrace Serial to your order.

Supports Trace for RISC-V - tested for SiFive Nexus IP - tested for Tessent Embedded Analytics (former UltraSoC) Trace Encoder IP other IP on request Please add the base serial number of your existing debug cable to your order.

Converter to connect an IDC20A debug cable to the 34 pin DEBUG connector on a PowerTrace Serial. MIPI-34 connector does not have key pin. For connecting an IDC20A debug cable to an AutoFocus-II-MIPI preprocessor (LA-3160) or an AURORA 2 preprocessor (LA-3945) use the converter LA-3770 instead. (LA-2770 is for a MIPI34 connector with pin 1 on the right sight, while LA-3770 expects pin 1 on the left side at the target.)

Converter JTAG-RH850 of LA-3719 (Debugger RH850 14pin) and from AUTO26 of LA-2709 (Debugger for RH850/V850 Automotive PRO) LA-3205 (Debugger for RH850/V850 AUTO26 (PACK)) LA-3739 (Debugger RH850 Automotive) and Samtec 40 pin of LA-3943 (Preproc. RH850 HSTP HF-Flex) to Samtec ERF 34-pin RH850 pinout Includes Samtec 34-pin flex extension
