EJTAG MIPS32 Converter Mictor38 to Samtec24 IN PRODUCT CATALOG
LA-7901 | On request, please contact Lauterbach

Converter for Preprocessor for MIPS Mictor38 to Samtec 24 to support IDT processor Target connectors: FTSH-112-04-L-DV (SMD, small height) FTSH-112-04-L-D (through-hole, small height) FW-12-05-L-D-XXX-150 (SMD, "XXX" selectable height) FW-12-02-L-D-XXX-150 (through-hole, "XXX" selectable height)

EJTAG MIPS32 Converter Mictor38 to Samtec52 IN PRODUCT CATALOG
LA-7903 | On request, please contact Lauterbach

Converter for Preprocessor for MIPS Mictor38 to Samtec52 to support Micronas MDEB (Lexra LX4280) processor Target connector: FTSH-126-04-L-DV (SMD, small height) FTSH-126-04-L-D (through-hole, small height) FW-26-05-L-D-XXX-150 (SMD, "XXX" selectable height) FW-26-02-L-D-XXX-150 (through-hole, selectable height)

Preprocessor for MPC880 and MPC885 TCON IN PRODUCT CATALOG
LA-7905 | Out of production

Trace Preprocessor for MPC880 and MPC885, connection to TCON320, 80 MHz bus clock

EJTAG MIPS32 Converter Mictor38 to Samtec52 IN PRODUCT CATALOG
LA-7908

Converter for Preprocessor for MIPS Mictor38 to Samtec52 to support Micronas MDED (Lexra LX4280) processor Target connector: FTSH-126-04-L-DV (SMD, small height) FTSH-126-04-L-D (through-hole, small height) FW-26-05-L-D-XXX-150 (SMD, "XXX" selectable height) FW-26-02-L-D-XXX-150 (through-hole, selectable height)

Converter Mictor38 to Samtec40 for PP-MIPS IN PRODUCT CATALOG
LA-7909 | On request, please contact Lauterbach

Converter for Preprocessor for MIPS64 Mictor38 to Samtec40 to support TOSHIBA RBTX49xx EVBs

CombiProbe Hardware V2 IN PRODUCT CATALOG
LA-3060

CombiProbe 2 base hardware. Requires suitable Whisker-Cable to connect to target. Requires Power Debug Interface USB 3.0, PowerDebug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50. This TRACE32 product is a license carrier. Requires a suitable, programmed TRACE32 A-license.

CombiProbe 2 for MIPI20T-HS (PACK) IN PRODUCT CATALOG
LA-3080

CombiProbe 2 with MIPI20-HS whisker for debugging and tracing. Voltage Range: 1.2V...5.0V. Target Connector: MIPI20T, MIPI10 Trace Memory: 512 MByte. Maximum Trace Port Width: 4 pins. Maximum Trace Bandwidth: 400 MBit/s per trace pin. Includes the TRACE32 software for Windows, Linux and macOS on DVD and for download. Requires at least one of the following A-licenses: LA-3743A Debug. for Cortex-A/R (Armv8 and Armv9) Add. LA-7844A Debug Cortex-M (Armv6/7/8 32-bit) Add. LA-7843A Debug Cortex-A/-R (Armv7 32-bit) Add. LA-7765A JTAG Debugger License for Arm11 Add. LA-7742A JTAG Debugger License for Arm9 Add. LA-7746A JTAG Debugger License for Arm7 Add. LA-2540A Debugger for RISC-V 32-bit Add. LA-2541A Debugger for RISC-V 64-bit Add. Requires trace license LA-7970X for on-chip ETM traces of Cortex-A/R. Requires trace license LA-2767X for RISC-V off-chip traces emitted via a 4-bit Pin Interface Block (PIB). Requires Power Debug Interface USB 3.0,PowerDebug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50. Extend your CombiProbe with a Mixed-Signal Probe (LA-2500), to record and correlate digital and analog signals.

CombiProbe 2 for AUTO26 (PACK) IN PRODUCT CATALOG
LA-3081

CombiProbe 2 with AUTO26 Whisker for debugging and DAP Streaming, supporting DAP (DAP2, DAP3, DAP4, DAPWide), JTAG, DXCPL/DXCM. For optimal performance, we recommend using a DAP mode. DAP streaming is supported for TriCore (in DAP mode) and works most effectively with DAPWide (up to 320 Mbit/s). For DXCPL/DXCM, you will likely require the CAN-Box (LA-3889) as well. Voltage Range: 1.8V to 5.0V. Debug Clock Frequency: 10 kHz to 160 MHz Target Connector: AUTO26, AUTO20, AUTO10 Trace Memory: 512 MByte. Includes the TRACE32 software for Windows, Linux and macOS on DVD and for download. Requires the following A-license: LA-7756A (Debugger for TriCore Standard Additional). Trace analysis and display requires LA-3799X (Trace License for TriCore ED). Requires Power Debug Interface USB 3.0,PowerDebug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50. Please note that TriCore SoCs usually support only 3.3V or 5V in DAP mode. Debug clock frequency in JTAG mode is typically limited to 40 MHz on TriCore SoCs (while up to 160 MHz is supported in DAP mode). Extend your CombiProbe with a Mixed-Signal Probe (LA-2500), to record digital and analog signals and correlate them with MCDS DAP streaming. (Requires PowerView R.2024.02 or higher). Alternatively extend your CombiProbe with a second AUTO26 Whisker (LA-4553) and a multicore license (LA-7960X) to debug and trace two TriCore chips simultaneously. (Req. PowerView R.2024.09 or higher).

CombiProbe 2 for MIPS32+4-Bit IFLOW (PACK) IN PRODUCT CATALOG
LA-3082

CombiProbe 2 to debug and trace MIPS32 CPUs with 4 Bit IFLOW trace. Voltage Range: 1.2V...3.3V (5V tolerant inputs). Target Connector: MIPI34, MIPI20T, MIPI10, eJTAG/IFLOW. Trace memory: 512 MByte. Maximum trace port width: 4 pins. Maximum trace bandwidth: 200 MBit/s per trace pin. Iincluded adapter for eJTAG and IFLOW connector. Includes the TRACE32 software for Windows, Linux and macOS on DVD and for download. Requires the following A-license: LA-7760A (JTAG Debugger for MIPS32). 4-Bit IFlow program trace requires: LA-7971X (Trace License for the MIPS32). Requires TRACE32 Software R.2022.02 (build 142224) or newer. Requires Power Debug Interface USB 3.0, PowerDebug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50. Extend your CombiProbe with a Mixed-Signal Probe (LA-2500), to record and correlate digital and analog signals.

CombiProbe 2 for MIPI34 (PACK) IN PRODUCT CATALOG
LA-3083

CombiProbe 2 with MIPI34 whisker for debugging and tracing. Voltage Range: 1.2V...3.3V (5V tolerant inputs). Target Connector: MIPI34, MIPI20T, MIPI10 Trace memory: 512 MByte. Maximum trace port width: 4 pins. Maximum trace bandwidth: 200 MBit/s per trace pin. Includes the TRACE32 software for Windows, Linux and macOS on DVD and for download. Requires at least one of the following A-licenses: LA-3743A Debug. for Cortex-A/R (Armv8 and Armv9) Add. LA-7844A Debug Cortex-M (Armv6/7/8 32-bit) Add. LA-7843A Debug Cortex-A/-R (Armv7 32-bit) Add. LA-7765A JTAG Debugger License for Arm11 Add. LA-7742A JTAG Debugger License for Arm9 Add. LA-7746A JTAG Debugger License for Arm7 Add. Requires trace license LA-7970X for on-chip ETM traces of Cortex-A/R. Requires Power Debug Interface USB 3.0, PowerDebug II, PowerDebug PRO, PowerDebug E40 or PowerDebug X50. Extend your CombiProbe with a Mixed-Signal Probe (LA-2500), to record and correlate digital and analog signals.
