Supports off-chip trace port for C64x+ if applied to an AUTOFOCUS II preprocessor please add the serial number of the preprocessor to your order AUTOFOCUS II Preprocessors with serial number C0806xxxxxx and lower have to be send to Lauterbach Germany for an hardware upgrade
Preprocessor for Real-Time Trace of TEAKLITE-III 500 MHz clock speed Variable threshold level and termination voltage, AUTOFOCUS self calibration technology, Supports 1.2 to 3.3V - else contact support Requires PowerTrace Version 6 or higher or PowerTrace II / III voltage range 1.2V to 3.3V
Supports off-chip trace port for TEAKLITE-III if applied to an AUTOFOCUS II preprocessor please add the serial number of the preprocessor to your order AUTOFOCUS II Preprocessors with serial number C0806xxxxxx and lower have to be send to Lauterbach Germany for an hardware upgrade
Preprocessor for RAM Trace Port on TI chips 500 MHz clock speed Variable threshold level and termination voltage, AUTOFOCUS self calibration technology, Supports 1.2 to 3.3V - else contact support Requires PowerTrace Version 6 or higher or PowerTrace II / III May require LA-3835 Converter Mictor38/ETM+IDC20A to Mictor-38/RTP voltage range 1.2V to 3.3V
Supports off-chip RAM trace port for of TI chips if applied to an AUTOFOCUS II preprocessor please add the serial number of the preprocessor to your order AUTOFOCUS II Preprocessors with serial number C0806xxxxxx and lower have to be send to Lauterbach Germany for an hardware upgrade May require LA-3835 Converter Mictor38/ETM+IDC20A to Mictor-38/RTP
Preprocessor for Real-Time Trace of MIPS32 EJTAG 2.6 derivatives or higher 600 MBaud (300MHz clock speed, DDR) Variable threshold level and termination voltage, AUTOFOCUS self calibration technology, Supports 1.2 to 3.3V - otherwise contact support Requires PowerTrace II, PowerTrace PX or PowerTrace/Ethernet Version 6 or higher voltage range 1.2V to 3.3V
Preprocessor for Intel® Processor Trace 600 MBaud (300MHz clock speed, DDR) Variable threshold level and termination voltage, AUTOFOCUS self calibration technology, Supports 1.2 to 3.3V - otherwise contact support Requires PowerTrace II / III voltage range 1.2V to 3.3V
Trace license to support the decoding of Intel Processor Trace applicable to an AutoFocus II or AutoFocus MIPI preprocessor. If the license is applied to an AutoFocus II preprocessor, the preprocessor must have a base serial number of C1210xxxxxxx or higher. Please add the base serial number of your existing preprocessor to your order.
Preprocessor for Beyond BA2x cores Instruction trace only 600 MBaud (300MHz clock speed, DDR) Variable threshold level and termination voltage, AUTOFOCUS self calibration technology, Supports 1.8 to 3.3V - otherwise contact support Requires PowerTrace II, PowerTrace PX or PowerTrace/Ethernet Version 6 or higher May require LA-3804 Converter Mictor 38 to XILINX XGI voltage range 1.2V to 3.3V
Preprocessor for RH850 and V850 with parallel Nexus trace interface Voltage range: 1..5 V TRACE port: 2..16 MDO (data) lines 1..2 MSEO (control) lines Data Bandwidth: up to 200 MBit/s Connector: 76 pin mictor connector requires PowerTrace II
